作业系统 |
Windows CE.NET 6.0
中文/English/German 多国语言 |
|
CPU |
ARM11 - 667 MHz |
|
Audio |
Speaker (MIC inside) |
|
LED Indicator |
Dual colors (green/red) for indication. (Scan Flash) |
|
Display |
2.8” TFT with touch panel, 240x320 pixel type. |
|
Software |
提供机器各硬体之控制API |
|
Keyboard |
Total 31 hard keys. |
|
UART |
内置COM port |
|
USB |
USB *1 |
|
Power |
DC adapter/Battery/ data backup battery |
|
Battery |
3200mAH main battery+ data backup battery. |
|
Usage Hours |
8hrs+ |
|
Charging |
5 hrs. |
|
Drop test |
1.2m 以上水泥地 |
|
Dimensions |
L<170mm;D<30mm;W<70mm |
|
Weight |
含电池约300g. |
|
Temperature |
使用-15度~+60度；保存-20度~+80度 |
|
Scanner |
DataBar Limited; GS1 DataBar Expanded;UPC-A; UPC-E; UPC-E1; EAN-8; EAN-13;
2D Barcode |
|
3G mobile
|
WCDMA UMTS Tri Band(HSPA Class 3/EDGE class 12);
GSM 850/900/1800/1900 (optional CDMA2000 1X/EV-DO ) |
|
GPS |
NMEA0183,GGA,GSA,GSV,RMC,VTG |
|
DSC |
3M DSC, with API control, LED补光 |
|
IrDa |
SIR (with IR com port) |
|
WLAN |
802.11b.g with good performance PIFA antenna. |
|
Bluetooth |
With SPP profile (for BT printer) |
|
User Extendable |
With internal COM port/power, user extendable such as Magnetic card、IC card . |
